Environmental Test Chamber UV Aging Chamber Complies with ASTM G154 and IEC 61215

Environmental Test Chamber UV Aging Chamber Complies with ASTM G154 and IEC 61215

Marchio:	Sinuo
Numero di modello:	SN882B
MOQ:	1
prezzo:	Customized
Condizioni di pagamento:	T/T
Capacità di approvvigionamento:	20 set/mese

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

Cina

Certificazione:

Calibration Certificate (Cost Additional)

Corrente massima:

15A

Massima potenza:

3KW

Potenza della lampada:

40 W

Zona di collocazione del campione:

WDH=1140*600*500 mm

Durata di vita della lampada:

Oltre le ore 16.00

Lunghezza della lampada:

1220 mm

Spazio di forma:

WDH=1400*1750*750 ((mm)

Dimensione del campione:

WDH=1100*600*500 ((mm)

Imballaggi particolari:

Custodia in compensato

Capacità di alimentazione:

20 set/mese

Evidenziare:

40W Lamp Power Environmental Test Chamber

1600h Lamp Lifespan UV Aging Chamber

ASTM G154 Weathering Test Chamber

Descrizione del prodotto

Environmental Test Chamber for UV Aging and Environmental Stress Simulation

This ISO4892-3 compliant UV Aging Chamber uses fluorescent ultraviolet lamps to simulate sunlight's UV spectrum, combined with temperature control and humidity systems to replicate environmental factors that cause material degradation including discoloration, strength reduction, cracking, peeling, and oxidation.

Compliance Standards

ISO 11507
ISO4892-3
ASTM G154
ASTM G153
ASTM4329
IEC 61215

Equipment Overview

The chamber simulates damage from sunlight (UV band), high temperature, high humidity, condensation, and dark cycles. Through the synergistic effect between ultraviolet light and humidity, it evaluates material weather resistance by testing both light and moisture resistance simultaneously.

Technical Specifications

Parameter	Specification
Model	SN882B
Sample Size	WDH=1100600500(mm) Inner size sample
Sample Placement Area	Chamber type WDH=1140600500(mm)
Shape Space	Approximately 14001750750(mm) WHD
Center Distance Between Lamps	70mm
Sample Test Surface to Lamp Center	50±3 mm
Nozzle Quantity	Top row 4 pcs
Spraying Pressure	70～200Kpa adjustable
UV-B Lamp Irradiation	0～0.9 W/m² at 313nm, adjustable
UV-A Lamp Irradiation	0～0.9 W/m² at 340nm, adjustable
Lamp Length	1220mm
Lamp Power	40W
Lamp Lifespan	More than 1600 hours
Number of Lamps	8 pcs lamps in top row (UV-A/UV-B selectable, defaults to UV-A)
Weight	80 kg
Maximum Power	3 KW
Maximum Current	15A
Power Supply Requirements	AC 220V single-phase, ±10% voltage fluctuation, 50/60Hz frequency, TN-S or TT power supply, protective grounding resistance less than 4Ω
